1.5 HP Waterway Executive Spa Pump 2 Speed 115V 3420610-1A

Pump, Waterway Executive 48, 1.5HP, 115V, 16.4/4.4A, 2-Speed, 2"MBT, SD, 48-Frame, 16.4/4.4Amps
SKU
3420610-1A
Product Availability

Notify me when this product is in stock

1.5 HP Waterway Executive Spa Pump 2 Speed 115V 3420610-1A
Committed to innovation & excellence since 1973
Executive wet end designed to fit 48-frame motors with large 2" intake for improved flow performance and reduced noise. Thermally protected to extend life expectancy of motor.

Features

  • Executive wet end designed specifically for 48-frame motors
  • Large 2" intake for improved flow performance and reduced noise
  • Large 6" diameter wet end for higher head pressure

NOTE - Does not include unions or pump cord


*Product Change Notification*
Product- All Executive Wet Ends and Pumps
In order to accommodate for the growing demand of wet ends and pumps, Waterway will be removing two of the three drain plugs located on the front of the wet end. The two side ports are rarely used. For those instances where they’re required, the drain plug ports can still be drilled and tapped on location. This change will be introduced as a running change starting immediately.
If you have any questions regarding this notification, please contact a technician or customer service representative to assist you.


**Pump & motor manufacturers reserve the right to change motors on pumps or style of motor without notice. Motors shown may differ from current stocked product. Functionality remains the same**

Additional Information
Cord Type NONE
Voltage 115
Horsepower 1.5
Discharge Location Side
Discharge Size 2" MBT
Frame Size 48Y
Number of Speeds 2
Frequency (Hz) 60
High Speed (Amp) 16.4
Lo Speed (Amp) 4.4
Alternate Part Numbers
Available Documentation
  • 1-00-0082
  • 34206101A
  • WW34206101A
  • 15-350-4014
  • PF-15-2N11C4
  • 3420613-1A86
  • 3420610-1AHZW
  • PF-15-2N11C4
  • PF-30-2N11C4
  • 3420613-1A86
  • PF-15-2N11M4
  • 34206101A
  • 342061A-1A
  • 34-270-3202W
  • 34-270-3202W
  • 34-270-3202N
  • 34-270-3202
